Standard Function:
Counting display,easy reading,1000pcs PLU data,inside label printer,label edit program
High precision A/D conversion with readability 1/30000
AC/DC power supply, with inside rechargeable 6V/4AH battery
Able to setup zero-tracking range
Able to setup print function
Standard RS232 communication interface with selectable baud rate and communication method
Technical Parameter:
A/D conversion method: ∑‑–△
A/D conversion speed: 8 times/sec.
Max. A/D conversion bits: 20
Verified counts: 30000
Display: 667 LCD, 8 status indications
Power supply: AC 110~230V, 50～60Hz; DC inside rechargeable 6V/4AH battery
Paper size:wide 50mm,diameter 38mm
|
Model
|
ACS/PC-L3K
|
ACS/PC-L6K
|
ACS/PC-L15K
|
ACS/PC-L30K
|
|
Capacity
|
3kg
|
6kg
|
15kg
|
30kg
|
|
Division
|
0.1g
|
0.2g
|
0.5g
|
1g
|
|
Resolution
|
1/30000
|
1/30000
|
1/30000
|
1/30000
|
|
Repeatability+
|
0.1g
|
0.2g
|
0.5g
|
1g
|
|
Linearity +
|
0.1g
|
0.2g
|
0.5g
|
1g
|
|
Measure unit
|
can be set by soft
|
|
Response
|
2 Secs
|
2 Secs
|
2 Secs
|
2 Secs
|
|
Temperature
|
0°C to +40°C / +32°F to +104°F
|
|
Power display
|
Input 110~220V AC / Output 12V DC 3A
|
|
Calibration
|
Manual calibration
|
|
Calibration weight
|
500g-3000g
|
1kg-6kg
|
5kg-15kg
|
5kg-30kg
|
|
Display
|
LCD display 667 digits
|
|
Appearance
|
ABS, with stainless steel platform
|
|
Pan size
|
260 x 218mm
|
|
Scale size
(w x d x h)
|
275 x 310 x 95mm
|
|
Net weight
|
3.27kg
|
|
